1MINI Reset & Teardown (FCC ID 2BDC6-1MINI)

EN
USER AND SAFETY GUIDE
Wi-Fi smart switch with potential-free contacts
Shelly Plus 1 Mini
Read before use
This document contains important technical and safety informa-
tion about the device, its safe use and installation.
⚠ CAUTION! Before beginning the installation, please read care -
fully and entirely this guide and any other documents accompany -
ing the device. Failure to follow the installation procedures could
lead to malfunction, danger to your health and life, violation of law
or refusal of legal and/or commercial guarantee (if any). Shelly
Europe Ltd. is not responsible for any loss or damage in case of
incorrect installation or improper operation of this device due to
failure of following the user and safety instructions in this guide.
Product Introduction
Shelly® is a line of innovative microprocessor-managed
devices, which allow remote control of electric circuits
through a mobile phone, tablet, PC, or home automation sys -
tem. Shelly® devices can work standalone in a local Wi-Fi
network or they can also be operated through cloud home auto -
mation services. Shelly Cloud is a service that can be accessed
using either an Android or iOS mobile application or with any
internet browser at https:/ /control.shelly.cloud/. Shelly® devic -
es can be accessed, controlled, and monitored remotely from
any place where the user has internet connectivity, as long as
the devices are connected to a Wi-Fi router and the Internet.
Shelly® devices have an Embedded Web Interface accessible at
http:/ /192.168.33.1 when connected directly to the device access
point, or at the device IP address on the local Wi-Fi network. The
embedded Web Interface can be used to monitor and control the
device, as well as adjust its settings.
Shelly® devices can communicate directly with other Wi-Fi devic-
es through HTTP protocol. An API is provided by Shelly Europe
Ltd. For more information, please visit:
https:/ /shelly-api-docs.shelly.cloud/#shelly-family-overview.
Shelly® devices are delivered with factory-installed firmware. If
firmware updates are necessary to keep the devices in conformi-
ty, including security updates, Shelly Europe Ltd. will provide the
updates free of charge through the device Embedded Web Inter -
face or the Shelly mobile application, where the information about
the current firmware version is available. The choice to install or
not the device firmware updates is the user’s sole responsibility.
Shelly Europe Ltd. shall not be liable for any lack of conformity
of the device caused by failure of the user to install the provided
updates in a timely manner.
Schematic
L
SW OI LN
N
110 - 240 VAC
max. 240 VAC
max. 30 VDC
Fig. 1
Legend
Device terminals:
• SW: Switch input terminal
• O: Relay output terminal
• I: Relay input terminal
• L: Live (110-240 VAC) terminal
• N: Neutral terminal
Wires:
• N: Neutral wire
• L: Live (110 - 240 VAC) wire
Installation Instructions
Shelly Plus 1 Mini (the Device) is a small form facto...
